Switchboard panel and tube integrated laser cutting machine
- Cofiguration
Cutting width 1.5-2.5m
Cutting length 3.0-6.0m
Material thickness 0.5-35mm
- Optional
Fiber laser: MAX, Raycus,IPG,N-Light
Laser power: 500w -12000w
- Product Parameter
Empty running speed 120m/min
Acceleration 2.0G
Positioning accuracy + /-0.05mm/m
Repeat position accuracy + Z-0.03mm/m
Machine body and Beam
- Beam
Cantilever beam adopts the integral casting aluminum alloy, which ensure the high intensity and reduce the weight of the machine, reduced the Y axis of inertia in running at a high speed, which guarantees the machine in motion have a very high acceleration.
- Machine Body
Ductile cast iron casting structure is used in bed and the impact toughness, fatigue strength and vibration damping are good.
After the overall natural elimination ofintemal stress, aprecision machining process was competed with a large scale 5 axis machining center.
With high rigidity, the precision and stability of machine tool in high speed operation are guaranteed.
- Mechanical Parts
Body bed: ductile iron eating structure have high rigidity, good vibration damping,
Body bed: non-deformation, high accurancyand good stability
Beam: cast aluminum alloy, light load, ensure acceleration
Guideway: H-class linear guide, high precision, fast speed
Gear rack: precision gear rack, fast speed
Cut tube diameter: round 20-300 mm square 20-210 mm
Choice of chuck locking mode: 1. Manual 2. Automation
SWITCHBOARD PANEL TUBE LASER CUTTING MACHINE
